Cable Harness
VIBRAN designs and manufactures MIL-STD-1553 Data Bus Networks and Cable Harnesses to customer-specific requirements for Defence, Aerospace and Industrial applications.
Networks are supplied with customized bus and stub cable lengths, connector configurations and coupler arrangements for seamless integration into customer systems.
Our In-line Coupler based Network architecture minimizes the number of connectors and interconnections, resulting in improved system reliability, reduced installation effort and simplified maintenance.
Network Construction
Each MIL-STD-1553 Data Bus Network is designed and manufactured in accordance with customer requirements and applicable MIL-STD-1553 interface guidelines.
Key Features
- High reliability construction
- Lightweight and compact design
- Reduced installation time
- Eliminates field wiring errors
- 100% electrically tested
- Custom cable lengths and connector options
- Fast turnaround and delivery
- VIBRAN MIL-STD-1553 Data Bus Couplers (Type approved as per project/customer requirements)
- Raychem 10614-9 Twinax Cable
- M17/176-00002 Twinax Cable
- Raychem DK621 Series Connectors
- PL75-47 Connectors
- TWC-78-1 or equivalent Twinax Cable for laboratory test systems and simulators
Equivalent customer-approved cables and connectors can also be supplied on request.
Identification, traceability
and 100% electrical verification.
Identification & Traceability
Each network is supplied with:
- Cable identification labels
- Stub/LRU identification
- Connector identification
- Heat-shrink cable markers
- Serial number and traceability (optional)
Electrical Verification
Every manufactured network undergoes 100% electrical verification including:
- Visual Inspection
- Wiring Continuity
- Conductor-to-Shield Continuity
- Insulation Resistance
- Dielectric Withstanding Voltage (Hi-Pot)
